Forklift
| K系列2-4吨平衡重式内燃柴油叉车规格、性能、参数表 Forklift Specification | K系列2.0-4吨平衡重式内燃柴油叉车规格、性能、参数表 | |||||||||
| 概要 General | 1 | 型号 Basic Model | K20/H20T | K25/H25T | K30/H30T | K35/H35T | K40/H40T | |||
| 2 | 动力形式 Power type | 柴油 | 柴油 | 柴油 | 柴油 | 柴油 | ||||
| 3 | 额定起重量 Rated capacity | kg | 2000 | 2500 | 3000 | 3500 | 4000 | |||
| 4 | 载荷中心距 load Centre | mm | 500 | 500 | 500 | 500 | 500 | |||
| 特性及尺寸 Characteristic&Dimension | 5 | 起升高度 Lift height | mm | 3000 | 3000 | 3000 | 3000 | 3000 | ||
| 6 | 自由起升高度 Free lift height | mm | 130 | 130 | 140 | 145 | 150 | |||
| 7 | 货叉规格 Fork size | L×W×T | mm | 1070×100×40 | 1070×122×40 | 1070×122×45 | 1070×122×50 | 1070×122×50 | ||
| 8 | 门架倾角Mast tilt angle | 前/后 F/R | Deg | 6°/12° | 6°/12° | 6°/12° | 6°/12° | 6°/12° | ||
| 9 | 前悬距 Front overhang | mm | 441 | 441 | 460 | 465 | 485 | |||
| 10 | 后悬距 Rear overhang | mm | 520 | 520 | 550 | 550 | 590 | |||
| 11 | 最小离地间隙（门架处） Min. ground clearance(Bottom of mast) | mm | 115 | 115 | 135 | 135 | 135 | |||
| 12 | 外形尺寸 Overall dimensions | 长度（不带货叉） Length to face of fork (without fork) | mm | 2595 | 2595 | 2750 | 2750 | 2820 | ||
| 13 | 宽度 Overall width | mm | 1160 | 1160 | 1240 | 1240 | 1240 | |||
| 14 | 门架不起升高度 Mast lowered height | mm | 1980 | 1980 | 2070 | 2070 | 2070 | |||
| 15 | 门架起升高度（带档货架）Mast extended height (with backrest) | mm | 4050 | 4050 | 4065 | 4065 | 4065 | |||
| 16 | 护顶架高度 Overhead guard height | mm | 2220 | 2220 | 2220 | 2220 | 2220 | |||
| 17 | 转弯半径 Turning radius(outside) | mm | 2480 | 2480 | 2600 | 2600 | 2650 | |||
| 性能 Performance | 18 | 速度 Speed | 运行（空载） Travel(Unladen) | km/h | 19 | 19 | 19 | 19 | 19 | |
| 19 | 起升（满载）Lifting(Laden) | mm/sec | 540 | 540 | 430 | 400 | 400 | |||
| 20 | 下降（满载） Lowering(Laden) | mm/sec | 450 | 450 | 450 | 450 | 450 | |||
| 21 | 最大牵引力（满） Max. Drawbar pull(Laden/unladen) | KN | 17（14.5） | 17（14.5） | 18（15.7） | 18（18） | 18（18） | |||
| 22 | 最大爬坡度（满）Max. Gradeability(Laden) | % | 20 | 20 | 20 | 18 | 16 | |||
| 轮胎 Chassis | 23 | 轮胎 Tyre | 前 Front | mm | 7.00-12-12PR | 7.00-12-12PR | 28×9-15-12PR | 28×9-15-12PR | 28×9-15-12PR | |
| 24 | 后 Rear | mm | 6.00-9-10PR | 6.00-9-10PR | 6.50-10-10PR | 6.50-10-10PR | 6.50-10-10PR | |||
| 25 | 轮距 Tread | 前 Front | mm | 970 | 970 | 1000 | 1000 | 1000 | ||
| 26 | 后 Rear | mm | 980 | 980 | 980 | 980 | 980 | |||
| 27 | 轴距 Wheelbase | mm | 1650 | 1650 | 1750 | 1750 | 1750 | |||
| 重量 Weight | 28 | 自重 Self weight（含油水） | kg | 3260 | 3510 | 4100 | 4390 | 4550 | ||
| 29 | 桥负荷 Weight Distribution | 满载Laden | 前 Front Axle | kg | 4890 | 5410 | 6300 | 7080 | 7520 | |
| 30 | 后 Rear Axle | kg | 570 | 610 | 800 | 810 | 830 | |||
| 31 | 空载Unladen | 前 Front Axle | kg | 1510 | 1280 | 1536 | 1590 | 1600 | ||
| 32 | 后 Rear Axle | kg | 1750 | 2230 | 2546 | 2810 | 2950 | |||
| 动力与传动 Transmission | 33 | 蓄电池Battery | 电压/容量 Voltage/Capacity | v/Ah | 12/80 | 12/80 | 12/80 | 12/80 | 12/80 | |
| 34 | 发动机 Engine | 型号 model | QC490BPG | |||||||
| 35 | 制造商 Manufacture | 新柴(xinchai) | ||||||||
| 36 | 额定功率/转速 Rated output/r.p.m. | kw | 39/2650 | |||||||
| 37 | 最大扭矩/转速 Rated torque/r.p.m. | N-m | 160/1980 | |||||||
| 38 | 气缸数量 No.of Cylinder | 4 | ||||||||
| 39 | 缸径×行程 Bore×Stroke | mm | 90×100 | |||||||
| 40 | 排气量 Displacement | cc | 2540 | |||||||
| 41 | 燃油箱容积 Fuel Tank Capacity | L | 60 | 60 | 60 | 60 | 60 | |||
| 42 | 传动装置 Transmission | 制造商 Manufacture | CHINA | CHINA | CHINA | CHINA | CHINA | |||
| 43 | 型号 Type | 机械/液力 Mechanical/Automical | 机械/液力 Mechanical/Automical | 机械/液力 Mechanical/Automical | 机械/液力 Mechanical/Automical | 机械/液力 Mechanical/Automical | ||||
| 44 | 档位 Stage | 前/后 F/R | 1/1（2/2） | 1/1（2/2） | 1/1（2/2） | 1/1（2/2） | 1/1（2/2） | |||
| 45 | 工作压力 Operating pressure(For attachments) | Mpa | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | |||
